So, after a couple of seasons with my new 4-stroke 3.5hp engine (had to drop down to 3.5hp or face putting 80 pounds on the transom where formerly 40 pounds of 5hp had ridden), the engine just wasn’t as friendly to an all-outdoor environment as the old 2-stroke was. Happily, my mechanic was able to address – and explain – what the changes from 2-stroke to 4-stroke means. This column is about that.

The Old 2-Stroke engine – What is a “stroke”?

The basics of a 2-stroke engine versus 4-stroke engine has to do with what is known as “Thermodynamic” cycle. Basically in a 2-stroke engine, the beginning of a compression stroke and the end of the combustion stroke also occurs at the same time as the intake and exhaust functions. In a 4-stroke, each of these functions takes place within its own stroke. The return of the engine to its original position after going through these strokes is the “Thermodynamic” cycle – 2-strokes for the old model and 4-strokes for the newly legislated, current state of the art.

So, What’s the Problem?

A decade ago, the two-stroke motor, found on 75 percent of all boats and personal watercraft (jet skis), generated 1.1 billion pounds of hydrocarbon emissions each year. This was the annual equivalent of spilling as much oil and fuel into U.S. waterways as the Exxon Valdez – fifteen times over. These high emissions were attributed to the design inefficiency of the two-stroke engine, which had remained essentially unchanged since World War II. What made it so inefficient?

Largely, it was this – about a quarter of the fuel and oil, mixed directly into the furl, went unburned and thus was emitted directly into the water and air. Imagine having the gas dock operator selling you three gallons of gasoline and charging for four gallons, putting the pollution aside… The EPA estimated that one hour of operation by a 70-horsepower two-stroke motor emitted the same amount of hydrocarbon pollution as driving from New York to Los Angeles in a modern automobile –
and back.

Four-stroke engines emit 97% less pollution than conventional two-strokes. Why? Simple – 4-stroke outboards use the same combustion process used in automotive engines. This means that, unlike the 2-stroke engine, 4-stroke engines never have an exhaust and intake valve open at the same time. This keeps any unburned fuel from being ejected from the engine. Also, 4-stroke engines don’t require additional lubricating oil to be blended in with the gasoline to operate and aren’t part of the exhaust, unburned or otherwise. Like your car engine, the lubricating oil is a separate system within the engine complex, stored in the crankcase, unmixed with the gasoline. Also, they burn hotter, [read: more efficiently] and thus are more efficient at gas consumption. Manufacturers quote as much a 25% better fuel mileage. (Of course, slowing down would help even more – tests show that you burn over 50% more fuel at WOT than at mid-ranges. See what the effect on your speed over the water is if you just throttle back.)

OK, So What’s the Problem Now?

Well, they are heavy. When I went to replace my 5hp engine, I found that the 4-stroke replacement weighed 80 pounds – two times what the 2-stroke engine that it was to replace. When I contemplated trying to get that engine in and out of an 8-ft dinghy, floating dock-side, I said, “Ah, that’s not going to happen without me and/or the engine ending up in the drink – what’s the next size down?” 3.5hp in a 4-stroke weigh about what 5hp do in a 2-stroke. A car engine, not a weed whacker…

But the 2-stroke guys haven’t missed some this dialogue. The latest technology response is DFI – direct fuel injection. The required fuel mixture is injected directly into the cylinder after the piston passes the exhaust port. This prevents any unburned fuel from being prematurely forced out of the engine. DFI retains the advantages of a two-stroke engine’s efficient power cycle and lighter weight and greatly lowers pollution levels normally generated by 2-strokes. In short, they’re not your father’s 2-strokes any more. All this can’t be bad for boaters…

And many thanks to Roy Bartel of Remsenburg Marina for his staunch support of U.S. Coast Guard Forces… ■
